Carbon Fiber High-Voltage Wire Core Rod

This Carbon fiber high-voltage wire core rod product is made of highly conductive carbon fiber and has a strong tensile strength, capable of withstanding a tensile force of 2400Mpa. It operates within a temperature range of 0 to 200℃, with a 90% reduction in sag at high temperatures. The product is lightweight, with a density only a quarter of that of steel, which can reduce the burden on transmission lines. Its extremely high electrical conductivity can also reduce the operational loss of the lines. It has corrosion resistance and is suitable for core materials of transmission lines in high-load and harsh environments.

Quantity:
Availability:





Inquire Add to Basket

Product Description

Product Data

Project	Data	Project	Data
Application	Transmission line	Working temperature	0~200℃
Shape	Round rod	Corrosion-resistant	YES
Main material	Conductive carbon fiber	Tensile strength	2400 Mpa
Electrical conductivity	Excellence	Transmission loss	low
Colour	black	High modulus	YES
place of origin	China	Current-carrying capacity	high

Optical fiber bundled carbon fiber conductors have remarkable advantages and combine the merits of carbon fiber composite core conductors. With a parallel stranded structure, the core rods are evenly stressed and have high strength. They are protected by multiple layers, which makes them resistant to aging. Using the construction technology of steel-core aluminum stranded wires reduces the construction difficulty and cost. They have high toughness and can be detected online, preventing wire breakage. By using optical fibers to obtain operating condition parameters for smart power lines, they feature a strong and tough core, detectable wires, and low optical fiber attenuation.
